CER SM – G-STRUT EARTHQUAKE-RESISTANT HINGE CONNECTION

It is used to set up lateral and longitudinal supports.

  •  It can be directly fastened on concrete, and it is suitable for connecting 41×41 mm PF3 or PF3L strut channels to supporting structures in order to set up lateral and longitudinal supports.
  • It makes earthquake-resistant supports installation faster.
  • Thanks to the swiveling middle junction, it is possible to adjust the slope before tightening the bolts.

CER SM - G-STRUT EARTHQUAKE-RESISTANT HINGE CONNECTION

Download the Technical Sheet

Material technical data

MATERIAL = Steel DX51D EN 10142 with sendzimir zinc-plating
COD Type Description
161754CER SMFor 41x41mm G-strut channels
Aggiungi / Rimuovi
COD Type A B C D E F G L
161754CER SM38412,54243,5Ø 10,50Ø 129
Aggiungi / Rimuovi

Venduti in Cardboard box

COD Type
161754CER SM
Aggiungi / Rimuovi
